AirDesign RISE5 EN-B+
PRODUCT OVERVIEW
AirDesign RISE 5 — #whatsthetrick
The RISE 5 is AirDesign’s performance-focused EN-B, built around a 2.5-line layout and double-winglet concept. It targets pilots who want strong cross-country capability and accelerated performance while remaining within EN-B certification.
Where it sits
AirDesign positions the RISE 5 above the Vivo/LiVi progression wings, combining high-B performance with accessible behaviour for the class. EN-B covers a broad spectrum, so the RISE 5 should be considered a performance progression rather than simply another B wing.
Cloudbase perspective
The RISE 5 makes most sense for a current, experienced pilot deliberately looking for more cross-country capability within EN-B. Pilot experience, recent airtime, previous wing, intended flying and position in the certified weight range all matter. Talk to Cloudbase if you are deciding between the RISE 5 and a more accessible B-wing option.
Technical specifications
| Size | XXS | XS | S | M | L | XL |
|---|---|---|---|---|---|---|
| Flat area (m²) | 18.80 | 21.37 | 23.85 | 25.93 | 28.09 | 30.04 |
| Projected area (m²) | 16.06 | 18.26 | 20.38 | 22.15 | 24.00 | 25.67 |
| Flat span (m) | 10.49 | 11.18 | 11.81 | 12.32 | 12.82 | 13.26 |
| Projected span (m) | 8.41 | 8.97 | 9.47 | 9.88 | 10.28 | 10.63 |
| Flat aspect ratio | 5.85 | 5.85 | 5.85 | 5.85 | 5.85 | 5.855 |
| Projected aspect ratio | 4.4 | 4.4 | 4.4 | 4.4 | 4.4 | 4.4 |
| Chord (m) | 2.23 | 2.42 | 2.55 | 2.66 | 2.77 | 2.87 |
| Cells | 53 | 53 | 53 | 53 | 53 | 53 |
| Wing weight (kg) | 3.90 | 4.28 | 4.58 | 4.93 | 5.19 | 5.44 |
| Take-off weight (kg) | 50–65–72* | 60–78 | 72–92 | 85–105 | 100–120 | 115–135 |
| Certification | EN-B | EN-B | EN-B | EN-B | EN-B | EN-B |
*50–65 kg is the standard XXS all-up range; 65–72 kg is the extended certified all-up range.
Key design points
- 2.5-line architecture
- Double-winglet design
- Duralight construction
- B/C control
- S-Nose, Rigi-Rods, mini-ribs and 3D cut
Materials
Sail: Dominico 20DMF(WR) 35 g/m² top sail; Dominico 204432WR bottom sail; Dominico 204432FM ribs.
Lines: Edelrid 8001/U series. Risers: Cousin 13 mm Aramid. Maillons: 4.3 mm JOO-TECH.
Delivery
- Glider
- AirPack
- AirDesign goodies
- Repair materials and AirDesign stickers
